Ø Built in 16POE(4K) interfaces, supporting POE IPC direct power supply

Ø Support IEEE802.3af/at standard, compatible with power receiving equipment

(PD) supporting IEEE802.3af/at

Ø Support ONVIF protocol and can access cameras that meet ONVIF standards

Ø New GUI, convenient and easy to use, supports functions, such as automatic

addition, cross-network segment addition and other functions.

Ø The camera can be automatically reconnected after changing IP

Ø Support power amplifier speakers and 3.5mm audio output interface

Ø Support audio intercom (with headset two-in-one adapter)

Ø Support VGA、HDMI display simultaneously；HDMI maximum support 4K

Ø Support HDMI audio output；

Ø Support APP push alarm function

Ø Support cloud updating function；

Ø Support human detection, vehicle detection function；(need camera support)

Ø Support E-fence, line crossing, duty-off detection, passenger flow statistics (need

camera support)

Ø Support alarm linkage, local voice broadcasting and other functions, and support

intelligent playback of human detection, car detection；

Ø Support connect 16ch 4K cameras；

Ø Support ONVIF protocol

Ø Support GB28181 protocol to facilitate platform access

Ø Support network and USB backup function, and the backup can be accurate to

seconds

Ø Can control IPC image parameters setting.

Ø Support remote monitor and playback via EasyVMS

Ø APP P6SLite can be used for remote monitoring and playback of video;

Ø You can use APP P6SLite to scan the code and log in locally

RS-316PLJ-S2 16POE-4K_ EN_00.jpg

RS-316PLJ-S2 16POE-4K_ EN_00.jpg
