1. Product name: AHD HD module

2. Product model: RS-HD560-A0 series 8MP module (4-IN-1)

3. Technical characteristics：

3.1, C18 8MP high-definition image sensor, AHD/TVI/CVI 8MP output, CVBS output, effective

resolution up to 3840*2160;

3.2, OSD supports 11 languages, Support for white balance/gain modification/image enhancement

/ 2D denoise etc;

3.3. Use FH8538E DSP with OSD function (color/black and white, PAL/NTSC switch);

3.4 Double filter switch, day and night effect is clear, OSD switch a variety of day and night mode;

3.5, Support for coaxial audio transmission;

3.6 Support UTC function, support brightness/contrast/sharpness/saturation/noise reduction

modification;

3.7, power supply (600W) video (2KV) double lightning protection design, OSP anti-oxidation PCB,

small volume 38*38 bilateral frame design;

RS-HD560-A0 specification EN_00.jpg

RS-HD560-A0 specification EN.pdf
