1. Support onboard POE power supply: support 1236, 4578 power supply;

2. Support automatic identification of power receiving, support 12V output;

3. Support IEEE 802.3 series protocol power receiving and non-standard POE

equipment power receiving;

4. Support 1-2-3-6 and 4-5-7-8 eight cores to receive power at the same time;

5. Built-in dual-channel bridge rectifier, supports positive and negative line sequence

reverse connection;

6. Support H264, H.265 encoding format

Main stream: 5MP(2880*1624)/4MP(2560*1440)/3MP(2304*1296)/2MP(1920*1080)/

1MP(1280*720);

Sub stream: 448P(800*448)/D1(704*576)/360P(640*360)/CIF(352*288);

7. Support dual stream output at the same time;

8. Support digital wide dynamic range, 3D noise reduction, backlight compensation,

white balance, suitable for different monitoring environments;

9. Support ONVIF protocol, can access third-party NVR;

10. Support screen occlusion, which can cover the privacy area;

11. Support OSD character overlay function, support network time synchronization;

12. Support audio input and output, two-way intercom, audio and video

synchronization;

13. Support a variety of light board types, including hard light-sensitive and soft light-

sensitive light boards;

14. Support human figure detection function;15. Support linkage sound and light alarm;

16. Support automatic maintenance function;

17. Support mobile phone remote monitoring (iOS, android), support computer

remote monitoring

F5GPOE Intelligent sound light warning camera-EN_01.jpg

F5GPOE Intelligent sound light warning camera-EN_20240119180211.pdf
