Ø Built in 4POE(4K) interfaces, supporting POE IPC direct power supply

Ø Support IEEE802.3af/at standard, compatible with power receiving equipment

(PD) supporting IEEE802.3af/at

Ø Support 10ch 4K access; Support face capture and comparison function

Ø Face capture and comparison working mode: channel mode needs to be set

Camera capture and camera comparison mode: Connect 10ch face capture and

comparison cameras, allowing for full 10ch comparison; Camera: T5AI-F

Hybrid mode: Connect 10 ordinary cameras, select 1 channel to enable AI

function, then capture, and use other channels for ordinary monitoring

Support 4K output, HDMI supports synchronous audio output；

Ø Built in face library, can store up to 1000 faces；

Ø Support humanoid detection, face capture, and face comparison AI functions

Ø Support capturing faces and quickly storing them into the database, as well as

supporting batch import of faces into the database

Ø Support for searching videos by personnel name and face image, making video

query faster

Ø Support multiple comparison rules and can set different linkage functions；

Ø Support speaker interface for on-site monitoring；

Ø Support 3.5mm audio interface, expandable input and output

Ø Supports 2 HDD, with a maximum capacity of 14T；

Ø Video playback is displayed on a timeline, and the type of recording is

represented by color, making it convenient and fast to retrieve video data；

Ø Support video backup function, with backup accuracy up to seconds；

Ø Support batch modification of camera IP address, automatic mapping, and

mapping on different network segment

Ø Support ONVIF protocol；

Ø Can control IPC image parameters setting；

Ø Multiple playback modes, fast forward, fast rewind, and other functions；

Ø Support remote monitor and playback via EasyVMS；

Ø APP P6slite can be used for remote monitoring and playback of video；

RS-304PLJ-EN -Smart POE_00.jpg
