Ø 36-channel mode: 36-channel 5MP /25-channel mode: 25-channel 4K ;

Ø Support 4K video output, support HDMI synchronous audio output ;

Ø Support speaker interface, monitoring on-site sound from camera;

Ø Support mobile shared network;

Ø Support 3.5mm audio interface, expandable input and output;

Ø Support 4 hard disk access, each support maximum 8TB HDD

Ø Support human and vehicle detection and alarm function (requires camera support) ;

Ø Support electronic fence, cross-border detection, departure detection, passenger flow statistics (requires camera support) ;

Ø 36-channel mode: preview 4 sub-screen 5MP , 36 sub-screen 360P/25-channel mode:

preview 4 sub-screen 4K, preview 25 sub-screen 448P ;

Ø 36-channel mode: playback 4-channel 5MP/25-channel mode: 4-channel 4K;

Ø The video playback is displayed on the time bar , and the video type is indicated by

color, so it is convenient and quick to retrieve the video data;

Ø Support video backup function , the backup can be accurate to 1 second;

Ø Support batch modification of camera IP addresses , plug and play, and cross-network

segment image output functions ;

Ø Support ONVIF protocol;

Ø Support the function of controlling the image parameters of the camera ;

Ø Multiple playback modes, fast forward, fast rewind and other functions ;

Ø Support monitor and playback video remotely with EasyVMS software ;

Ø Support remotely monitor and playback video with P6SLite APP;


RS-N9936A-S4 datasheet_00.jpg
